Max Turbo Frequency
5.80 GHz
Intel® Thermal Velocity Boost Frequency
5.80 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡
5.70 GHz
Performance-core Max Turbo Frequency
5.40 GHz
Efficient-core Max Turbo Frequency
4.30 GHz
Performance-core Base Frequency
3.00 GHz
Efficient-core Base Frequency
2.20 GHz
Cache
36 MB Intel® Smart Cache
Processor Base Power
125 W
Maximum Turbo Power
253 W
Processor Graphics ‡ Intel® Graphics Technology for more information. Intel® Iris® Xe Graphics only: to use the Intel® Iris® Xe brand, the system must be populated with 128-bit (dual channel) memory. Otherwise, use the Intel® UHD brand." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Processor Graphics ‡ " data-target=".upe-modal" data-title="Processor Graphics ‡ " data-toggle="modal" style="font-family:inherit;font-size:1rem;margin:0px;line-height:1;appearance:button;cursor:pointer;font-weight:700;vertical-align:initial;background-image:none;border-width:0px;border-style:initial;border-color:initial;padding:0px;border-radius:0px;user-select:none;position:relative;min-width:1rem;height:auto;outline:0px;width:auto;box-shadow:none;" type="button">
Intel® UHD Graphics 770
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.65 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Max Resolution (HDMI) ‡
4096 x 2160 @ 60Hz
Max Resolution (DP)‡
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
5120 x 3200 @ 120Hz
Multi-Format Codec Engines
2
Intel® Quick Sync Video
Yes
Intel® Clear Video HD Technology
Yes
# of Displays Supported ‡
4
Intel® Gaussian & Neural Accelerator
3.0
Intel® Thread Director
Yes
Intel® Deep Learning Boost (Intel® DL Boost)
Yes
Intel® Speed Shift Technology
Yes
Intel® Thermal Velocity Boost
Yes
Intel® Turbo Boost Max Technology 3.0 ‡
Yes
Intel® Turbo Boost Technology ‡
2.0
Intel® Hyper-Threading Technology ‡
Yes
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Flex Memory Access
Yes
Intel® Volume Management Device (VMD)
Yes
Intel® Standard Manageability (ISM) ‡
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® AES New Instructions
Yes
Intel® Trusted Execution Technology ‡
Yes
Execute Disable Bit ‡
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Stable IT Platform Program (SIPP) Learn more about Intel® SIPP" data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Intel® Stable IT Platform Program (SIPP)" data-target=".upe-modal" data-title="Intel® Stable IT Platform Program (SIPP)" data-toggle="modal" style="font-family:inherit;font-size:1rem;margin:0px;line-height:1;appearance:button;cursor:pointer;font-weight:700;vertical-align:initial;background-image:none;border-width:0px;border-style:initial;border-color:initial;padding:0px;border-radius:0px;user-select:none;position:relative;min-width:1rem;height:auto;outline:0px;width:auto;box-shadow:none;" type="button">
Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
