Prices and specification and stock availability are subjected to change without prior notice please Contact Us to confirm. Thank you for choosing Gaming Store.
Stock Status: In Stock
Manufacturer: MSI
| Differences are marked in red | SPATIUM M480 PCIe 4.0 NVMe M.2 500GB | SPATIUM M480 PCIe 4.0 NVMe M.2 1TB | SPATIUM M480 PCIe 4.0 NVMe M.2 2TB |
|---|---|---|---|
| MODEL NAME | SPATIUM M480 PCIe 4.0 NVMe M.2 | ||
| CAPACITY | 500GB | 1TB | 2TB |
| CONTROLLER | PHISON E18 | ||
| FLASH MEMORY | 3D NAND | ||
| DRAM CACHE | 512MB DDR4 | 1GB DDR4 | 2GB DDR4 |
| FORM FACTOR | M.2 2280 | ||
| INTERFACE | PCIe Gen4x4, NVMe 1.4 | ||
| COMPATIBILITY | PCIe Gen4 / Gen3 / Gen2 / Gen1 | ||
| DIMENSIONS | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) | ||
| SEQUENTIAL READ UP TO (MB/S) | 6500 | 7000 | 7000 |
| SEQUENTIAL WRITE UP TO (MB/S) | 2850 | 5500 | 6800 |
| RANDOM READ 4KB UP TO (IOPS) | 170,000 | 350,000 | 650,000 |
| RANDOM WRITE 4KB UP TO (IOPS) | 600,000 | 700,000 | 700,000 |
| MAXIMUM OPERATING POWER (W) | 6.0 | 6.6 | 8.2 |
| IDLE POWER PS3 (MW) | 10 | 14 | 22 |
| LOW POWER L1.2 (MW) | 3 | ||
| OPERATING TEMPERATURES | 0°C – 70°C | ||
| STORAGE TEMPERATURES | -40°C – 85°C | ||
| TERABYTES WRITTEN (TBW) | 350 | 700 | 1400 |
| MEAN TIME BETWEEN FAILURE (MTBF) | Up to 1,600,000 Hours | ||
| LIMITED WARRANTY | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. | ||
| ADVANCED FEATURES | TRIM (Performance Optimization, OS support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) AES256/Pyrite (Encryption, Data Security) | ||
