Description: Intel UHD Graphics 770

Class: Desktop

Socket: FCLGA1700

Total Cores: 14 Cores, 20 Threads

Performance Cores: 6 Cores, 12 Threads, 2.5 GHz Base, 4.8 GHz Turbo

Efficient Cores: 8 Cores, 8 Threads, 1.8 GHz Base, 3.5 GHz Turbo

Typical TDP: 65 W

TDP Up: 154 W

Cache per CPU Package:
L1 Instruction Cache: 6 x 32 KB
L1 Data Cache: 6 x 48 KB
L2 Cache: 6 x 1280 KB
L3 Cache: 24 MB

Cache per Eff. CPU Package:
Eff. L1 Instruction Cache: 8 x 64 KB
Eff. L1 Data Cache: 8 x 32 KB
Eff. L2 Cache: 2 x 2048 KB

Memory Support: Max. Memory Size: 128 GB (Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s, ECC Supported)
