Description: Intel UHD Graphics 770

Class: Desktop

Socket: FCLGA1700

Total Cores: 12 Cores, 20 Threads

Performance Cores: 8 Cores, 16 Threads, 2.1 GHz Base, 4.9 GHz Turbo

Efficient Cores: 4 Cores, 4 Threads, 1.6 GHz Base, 3.6 GHz Turbo

Typical TDP: 65 W

TDP Up: 180 W

Cache per CPU Package:
L1 Instruction Cache: 8 x 32 KB
L1 Data Cache: 8 x 48 KB
L2 Cache: 8 x 1280 KB
L3 Cache: 25 MB

Cache per Eff. CPU Package:
Eff. L1 Instruction Cache: 4 x 64 KB
Eff. L1 Data Cache: 4 x 32 KB
Eff. L2 Cache: 1 x 2048 KB

Memory Support: Max. Memory Size: 128 GB (Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s, ECC Supported)
